Thermostatic Faucets

Model No. TYM-51 Bath and Shower Faucet

Specification:

1. The idea working pressure: 0.1 – 0.5 Mpa. ( 1 – 5 bar )

2. Cold water supply temperature: 4 – 29 degree C.

Hot water supply temperature: 55 – 85 degree C.

( Working temperature use from 55 to 65 degree C. suggestion )

3. Outlet water temperature range: 20 – 49 degree C.

4. Set the safety temperature at 38 degree C.

Model No. TYM-03 Bath and Shower Faucet

Specification:

1. The idea working pressure: 0.1 – 0.5 Mpa. ( 1 – 5 bar )

2. Cold water supply temperature: 4 – 29 degree C.

Hot water supply temperature: 55 – 85 degree C.

( Working temperature use from 55 to 65 degree C. suggestion )

3. Outlet water temperature range: 20 – 49 degree C.

4. Set the safety temperature at 38 degree C.

Model No. TLM-26 Shower Faucet

Specification:

1. The idea working pressure: 0.1 – 0.5 Mpa. ( 1 – 5 bar )

2. Cold water supply temperature: 4 – 29 degree C.

Hot water supply temperature: 55 – 85 degree C.

( Working temperature use from 55 to 65 degree C. suggestion )

3. Outlet water temperature range: 20 – 49 degree C.

4. Set the safety temperature at 38 degree C.

Model No. TLM-08 Shower Faucet

Specification:

1. The idea working pressure: 0.1 – 0.5 Mpa. ( 1 – 5 bar )

2. Cold water supply temperature: 4 – 29 degree C.

Hot water supply temperature: 55 – 85 degree C.

( Working temperature use from 55 to 65 degree C. suggestion )

3. Outlet water temperature range: 20 – 49 degree C.

4. Set the safety temperature at 38 degree C.

Model No. TLM-05 Shower Faucet

Specification:

1. The idea working pressure: 0.1 – 0.5 Mpa. ( 1 – 5 bar )

2. Cold water supply temperature: 4 – 29 degree C.

Hot water supply temperature: 55 – 85 degree C.

( Working temperature use from 55 to 65 degree C. suggestion )

3. Outlet water temperature range: 20 – 49 degree C.

4. Set the safety temperature at 38 degree C.

Model No. TXM-61 Basin Mixing Faucet

Specification:

1. The idea working pressure: 0.1 – 0.5 Mpa. ( 1 – 5 bar )

2. Cold water supply temperature: 8 – 29 degree C.

Hot water supply temperature: 55 – 85 degree C.

( Working temperature use from 55 to 65 degree C. suggestion )

3. Outlet water temperature range: 20 – 49 degree C.

4. Set the safety temperature at 38 degree C.

Model No. TXM-17 Basin Mixing Faucet

Specification:

1. The idea working pressure: 0.1 – 0.5 Mpa. ( 1 – 5 bar )

2. Cold water supply temperature: 8 – 29 degree C.

Hot water supply temperature: 55 – 85 degree C.

( Working temperature use from 55 to 65 degree C. suggestion )

3. Outlet water temperature range: 20 – 49 degree C.

4. Set the safety temperature at 38 degree C.

Model No. TMM-18 Basin Mixing Faucet

Specification:

1. The idea working pressure: 0.1 – 0.5 Mpa. ( 1 – 5 bar )

2. Cold water supply temperature: 8 – 29 degree C.

Hot water supply temperature: 55 – 85 degree C.

( Working temperature use from 55 to 65 degree C. suggestion )

3. Outlet water temperature range: 20 – 49 degree C.

4. Set the safety temperature at 38 degree C.
